For Atlas Drill Rigs, Hose Turntable 3128047510

Precision-Engineered Hose Turntable for Atlas Drill Rigs — Forged for Impact, Designed for Reliability

Essential forged hose turntable (P/N 3128047510) engineered exclusively for Atlas drill rigs. Optimized for high-impact mining, tunneling, and exploration drilling—featuring a robust 76mm diameter, precise 8.5mm thread pitch, and flush cleaning design to minimize downtime. Fully compatible with FT160A, FT160B, and FT160C air legs, and built to support accurate core sampling under demanding conditions.

Manufactured via hot forging for superior tensile strength and fatigue resistance—ideal for continuous operation in quarries, open-pit mines, and underground tunnels.

Key Advantages

  • Forged construction for maximum impact resistance and service life in heavy-duty drilling
  • 76mm diameter + 8.5mm thread pitch ensures secure, vibration-resistant mounting on Atlas rigs
  • Flush cleaning design enables rapid debris removal and reduces maintenance downtime
  • Full compatibility with FT160A / FT160B / FT160C air legs—no adapters required
  • Multiple face options (flat / convex / concave) for application-specific sealing and alignment
  • Available in gold, black, red, blue, and yellow anodized finishes for traceability and corrosion resistance

Applications

  • Underground and open-pit mining drilling operations
  • Tunnel boring and civil infrastructure excavation
  • Mineral exploration and geotechnical core sampling
  • Quarry blast-hole drilling with high-pressure air systems
  • Retrofit and OEM replacement for aging Atlas rig fleets
  • Drilling in abrasive, wet, or high-dust environments requiring reliability

Technical Specifications

Part Number3128047510
Diameter76 mm
Thread Pitch8.5 mm
Cleaning MethodFlush, Easy To Operate
Compatible Air LegsFT160A, FT160B, FT160C
Face Profile OptionsFlat / Convex / Concave
Manufacturing ProcessHot Forging
Color OptionsGold, Black, Red, Blue, Yellow

FAQ

Is this turntable a direct OEM replacement for Atlas Copco (now Epiroc) drill rigs?
Yes—3128047510 is dimensionally and functionally identical to the original Atlas Copco part and fits all standard Atlas drill rig models using the FT160 air leg platform.
What bit diameters is this turntable rated for?
It supports drill bits from 34–42 mm—optimized for medium-to-heavy rock drilling in mining and tunneling applications.
What is the typical lead time for bulk orders?
Standard lead time is 7–10 business days; expedited production (3–5 days) available for certified mining OEMs and distributors.
Does it require special tools or torque specs for installation?
No—uses standard M76×8.5 threading; recommended torque is 220–250 N·m with anti-seize compound for optimal thread integrity.

Detailed Description

For Atlas drill rigs, hose turntable 3128047510Product Specifications
AttributeValue
Cleaning MethodFlush, Easy To Operate
Bit Diameter34-42mm
ColourGold, Black, Red, Blue, Yellow
ProcessForging
SampleSupport
Diameter76mm
Air LegFT160A, FT160B, FT160C
FaceFlat / Convex / Concave
Product Description

This essential component for mining and construction operations provides durability and reliability in demanding environments. With a thread pitch of 8.5mm, these parts ensure secure fastening and stability during drilling activities.

The flush cleaning method enhances operational efficiency, allowing for easy maintenance with minimal downtime. Manufactured through forging, these parts offer exceptional strength and resilience to withstand high-impact forces in heavy-duty applications.

Designed to support sampling processes, they facilitate precise core sample extraction for accurate analysis. The 76mm diameter ensures compatibility with various drilling equipment, making them versatile for different drilling operations including exploration and production drilling.

Applications

These durable rock drill parts are engineered for demanding tasks in mining and construction industries. Suitable for drilling in tunnels, quarries, and open-pit mines, they deliver reliable performance in challenging environments.

Key features include:

  • C CA MBW Brass Design cage for exceptional support and stability
  • Available in multiple grades (YG6, YG8, YG8C, YG11) to match specific drilling requirements
  • Critical component for Truck Gateway Lifters operation
  • Ideal for both routine maintenance and heavy-duty drilling tasks
Technical Support & Services
  • Comprehensive troubleshooting assistance for performance issues
  • Expert guidance on maintenance and care to maximize part lifespan
  • Personalized recommendations for specific drilling requirements
  • Access to online resources including manuals and instructional videos
Packaging & Shipping

Packaging: Each part is securely packaged in sturdy cardboard boxes with protective padding to ensure safe delivery.

Shipping: We provide reliable shipping services with prompt order processing. Tracking information is provided for all shipments.
